The liquid packing machine with touch screen, is suitable for automatic packaging of liquid and paste materials in food, chemical, pharmaceutical and other industries, such as shampoo packaging, seasoning oil packaging, jam packaging, honey, juice drinks, alcoholic beverages, mineral water, pure water, oral liquid, milk tea, yogurt, fresh milk, liquid condiments, packaged beverage packaging.
Features
1. Simple and easy operation and repair, with high precision.
2. It uses step motor control, easy and accurate to set the bag length.
3. Simple circuitry and outstanding function
4.The machine automatically complete the whole procedure of filling, bag forming, sealing, date printing.
| Voltage (V/Hz) | AC 220V/50HZ 110V/60HZ |
| Power | 1.1KW |
| Packing range | 5-300ML |
| Packing speed | 20-40bag/min |
| Packing Film | Composite material:OPP/CPP,OPP/CE,MST/PE/PET/PE |
| Bag size | (L)40-200 * (W)25-150 MM (Customizable) |
| Sealing Type | 3 side sealing, back sealing, 4 side sealing |
| Measuring method | Piston |
| Machine material | Stainless steel |
| Weight | 300kg |
| Outline dimension | 730*750*1700 MM |
