Automatic edible oil jam sauce ketchup tracking type liquid piston filling machine

Item No.: 00293
Min.Order Quantity: 1 Set/Sets
Supply Ability: 500 Set/Sets per Month
Port: Guangzhou
Payment Terms: T/T,Western Union,paypal
Description
Description

Automatic sauce/jam/honey piston tracking filling machine

Tracking type piston filling machine consists of chain conveyor, bottle clamping automatic alignment mechanism, filling mechanism, automatic servo piston system, electric lifting adjustment mechanism, waterproof electric cabinet, touch man-machine operation interface, etc.Compared with other filling machine,this tracking type filling machine can control filling nozzle follow moving bottles during filling work.It reduce production error and improve filling accuracy.It is designed for filling paste like curry paste,tomato sauce,pepper sauce,each nozzle can be controlled separately.
Device model
Move double head
Move four heads
Six-head piston
Eight-headed piston
Ten-headed piston
Filling speed
1200-2100
2000-3000
1500-1850
2000-2500
2600-2800
Measuring range
100-3000ML(customizable)
Quantitative accuracy
±1%(Accuracy varies by capacity)
Operating Voltage
220V
Hopper capacity
150L
200L
150L
200L
200L
Overall dimension
2000*1200*2100
2200*1400*
2200
2000*1300*
2100
2100*1400*
2100
2200*1400*
2200



Guangdong Rifu Intelligent Equipment Co.,Ltd is an efficient and technology enterprise.Professional manufacturing filling machine,capping machine,labeling machine,filling sealing machine,vacuum packing machine,vertical packing machine,heat shrinking packingmachine,cellophane wrapping machine,etc.We have own excellent team and a high level of equipment manufacturing
personnel.Dedicated to strict quality control and thoughtful customer service.Has many of the world's countries and regions to establish long-term and friendly business.
